Model
|
|
[50Hz]
|
Cooling Only
|
|
Type
|
-
|
|
|
|
Tonnage Class
|
|
TR
|
1.5
|
|
Cooling Capacity Standard
|
|
Btu/h
|
18016 [8107 - 19818]
|
|
[Min. - Max.]
|
W
|
5280[2376 - 5808]
|
|
|
EER (W/W)
|
|
-
|
3.01
|
|
Electrical Data
|
Voltage
|
V-AC
|
230
|
|
Phase
|
|
Single Phase
|
|
|
Running Current
|
A
|
8
|
|
|
Power Input, Standard Cooling [Min. - Max.]
|
W
|
1757 [543 - 2370]
|
|
|
Moisture Removal Rate
|
|
l/h
|
1.2
|
|
Pt/h
|
2.5
|
||
|
Air Circulation (Indoor)
|
|
m3/min
|
16
|
|
ft3/min
|
565
|
||
|
Net Dimensions of the Indoor Unit
|
Length (L)
|
cm
|
107
|
|
Breadth (B)
|
cm
|
23.5
|
|
|
Height (H)
|
cm
|
29
|
|
|
Net Dimensions of the Outdoor Unit
|
Length (L)
|
cm
|
87
|
|
Breadth (B)
|
cm
|
28.8
|
|
|
Height (H)
|
cm
|
60.5
|
|
|
Noise Level
|
Indoor (H/Q)
|
[dB-A]
|
47/40
|
|
Outdoor
|
[dB-A]
|
53
|
|
|
Net Weight
|
IDU [ODU]
|
kg
|
11 [27.5]
|
|
IDU [ODU]
|
lb
|
24.2 [60.6]
|
|
|
Refrigerant
|
|
-
|
R-32
|
|
Operating Temp. Range
|
|
oC
|
16 ~ 52
|
|
Operating Volt. Range
|
|
V
|
145-285
|
|
Refrigerant Pipe Diameter
|
Liquid Side
|
cm
|
Ø0.635
|
|
Gas Side
|
cm
|
Ø1.270
|
|
|
Pipe Extension
|
Chargeless Pipe Length *
|
m
|
7.5
|
|
Maximum Pipe Length *
|
m
|
15
|
|
|
Maximum Elevation Length *
|
m
|
10
|
|
|
Additional Refrigerant Gas *
|
g/m
|
15
|
|
|
Power Supply Source
|
|
-
|
Indoor
|
10 Years’ Compressor & 01 Years’s Parts & Service
